JTM Products has two lines of Cutting and Grinding straight oils. The first is Kut Rite. These products are designed to be general purpose, multi-metal, multi-operations fluids ranging from light to heavy duty performance. The second is the Lube Rite Swiss oils. These products are more specifically designed to be run in Swiss Machining Centers were precision on small parts is necessary. Read on to learn more about both lines.

Kut Rite Cutting and Grinding Oils

JTM Product, Inc.’s Kut Rite family of cutting and grinding oils has been specifically designed to provide the optimum performance across a variety of different operational levels and viscosities. Straight oils are meant to be used in tougher operations where lubrication and extreme pressure properties are necessary.

Product Description
Kut Rite 1100 Low viscosity light duty oil that is designed to provide excellent wetting properties. Can be used in higher speed operations and swiss machines
Kut Rite 2200 Designed to provide good performance in light to moderate duty cutting applications, it can also be used as a dual or tri-purpose oil. The product is ideal for screw machines or any operation where this is a high probability of leakage.
Kut Rite 3300 Formulated to offer medium to heavy duty performance at a higher viscosity. The product has been fortified with lubricity and extreme pressure additives that are ideal for gear hobbing, gear shaping, threading, and tapping applications.
Kut Rite 4200 and 4210 Highly fortified heavy duty products designed to offer protection during even the most difficult machining operations including, but not limited to; pip threading, tapping, reaming, or internal broaching.
Kut Rite 1100 2200 3300 4210 4200
Machinability Light Light-Moderate Moderate-Heavy Heavy Heavy
Appearance Light straw Amber Amber Straw Light Amber
Viscosity @ 40 ºC, cSt 10 32 40 22 32
Viscosity @ 100 ºF, SUS 60 150 190 106 150
Specific Gravity at 15.6 ºC 0.91 0.93 0.95 0.97 0.97
Density, lbs / gallon 7.59 7.76 7.92 8.09 8.09
Sulfur No No No Yes Yes
Chlorine Yes Yes Yes Yes Yes




Lube Rite Swiss Cutting Fluids

Caption: High Precision CNC Machining Center

The Lube Rite series of products provide quality swiss machining lubricants that are designed to enhance tool life and provide exceptional surface finish in high-precision metal removal applications. Lube Rite oils are formulated to prevent welding of the tool and work piece, resulting in improved surface finish.



Applications


Example of a small part that can be machined with Swiss Oils
• Machining of tough alloys such as stainless steel, titanium, and high temperature alloys.
• Easy cleanability makes them ideal for medical industry applications.
• Machining of very small or miniature parts.
• Machining of long slender parts.
• Any application where tight tolerances are necessary.


Performance Features and Benefits

• Low viscosity formulations allow for flow of lubricant to the point of cut in small parts.
• Parts clean easily in aqueous cleaning systems.
• High flash points reduce the risk of fire.
• Vegetable oil formulations are gentle on skin.
• The multi-purpose Lube Rite 2102 may be used in both the cutting side as well as the bar feeder.

LubeRite Way Oil 22 15 22
ISO Grade 22 15 22
Viscosity, cSt at 40 °C 22 15 22
Viscosity, cSt at 100 °C 5.9 4.5 4.24
VI Index 239 242 91
Total Acid Number 5 5 0.28
Flash Point, °F 375 333 234
Oil Type Vegetable Vegetable Mineral
Specific Gravity at 15.6 °C 0.875 0.879 0.886


Why Consider Vegetable Oils?

Compared to mineral oil-based products, vegetable oil formulations can offer improvements in tool life, lubricity, and part finishes while providing a cleaner and safer work environment. It should be noted that vegetable oils do not perform well in the presence of moisture or water.
